PE MINING HOSE
Details About PE MINING HOSE
Specification:
diameter: Φ 25-110mm, folded diameter: 39-173mm,
thickness: 0.2-0.4mm, 0.3-0.5mm
holes space: >150~>300mm
Package: 200m/roll.
Micro Spraying Tape Sizes:
|
Size |
Thickness
(mm) |
Holes Space
(mm) |
Holes Type | Rated Working
Pressure (Mpa) |
Paving Length
(m) |
Spraying
Width (m) |
Length (m) |
|
| Diameter
(mm) |
Folded Diameter |
|||||||
|
Ø 25 |
39 | 0.2-0.4 | ≥150 | Sloping 2 holes | 0.1 | 50 | 2 |
200 |
|
Ø 32 |
50 | 0.2-0.4 | ≥150 | Sloping 3 holes | 0.1 | 50 | 3 |
200 |
|
Ø 40 |
63 | 0.2-0.4 | ≥150 | Sloping 3 holes | 0.1 | 80 | 3 | 200 |
| Ø 50 | 78.5 | 0.2-0.4 | ≥200 | Sloping 5 holes | 0.1 | 100 | 4 |
150 |
|
Ø 63 |
99 | 0.2-0.4 | ≥250 | Sloping 5 holes | 0.1 | 100 | 4 | 150 |
| Ø 75 | 118 | 0.2-0.4 | ≥250 | Sloping 5 holes | 0.1 | 100 | 6 |
150 |
|
Ø 90 |
141 | 0.3-0.5 | ≥300 | Sloping 7 holes | 0.1 | 150 | 7 | 100 |
| Ø 110 | 173 | 0.3-0.5 | ≥300 | Sloping 7 holes | 0.1 | 150 | 8 |
100 |
