PU REHABILITATION HOSE
This lay flat hose is innovated for prolonging the life of pipelines. It is mainly applied as a function inhabitation for corroded pipelines, without digging leaking sections out and replacing them with new pipes. It is a lay flat hose of high strength, with PE, PVC, or TPU as cover, and TPU, HDPE, PA, or PVDF as inner lining, its reinforcement layer is made of polyester or aramid fiber.
Details About PU REHABILITATION HOSE
Lining with a circular woven reinforced textile which is either permanently restructured to provide a pipe after installation or inflates when fluid is transported under pressure, without bonding to the existing pipe.
Features
- Anti-corrosion: Non-metal lifetime ＞ 20years
- Extensive Diameter: Covering DN50-DN1200
- Disturbance resistance: Liner with flexibleness/self-support that can avoid influence from disturbance.
- Pressure self-support: W.P. 2.0MPa, B.P. 6.0MPa for bare line
- Pollution-free: TPU/PE is Polymer, 100% branded fresh material
- Fast construction speed: 1km/3hr, temporary on ground hose available
- Long-distance: Max. length 5.0km on one pull
Technical Data
|
Inner diameter (mm) |
Design pressure (MPa) | Burst pressure(MPa) |
Reinforcement material |
|
DN50 |
8.0 | 16/24 | Polyester |
| DN80 | 8.0 | 16/24 |
Polyester |
|
DN100 |
8.0 | 16/24 | Polyester |
| DN127 | 7.0 | 14/21 |
Polyester |
|
DN150 |
6.0 | 12/18 | Polyester |
| DN200 | 5.0 | 10/15 | Polyester |
| DN250 | 4.5 | 9.0/13.5 | Polyester |
| DN300 | 4.2 | 8.4/12.6 | Polyester/Kevlar |
| DN400 | 4.2 | 8.4/12.6 | Polyester/Kevlar |
| DN500 | 4.0 | 6.0/12 | Polyester/Kevlar |
| DN600 | 2.0 | 4.0/6.0 | Polyester/Kevlar |
| DN800 | 2.0 | 4.0/6.0 |
Polyester/Kevlar |
Process
Application
